Faital PRO HF201 - 2" kompressionsdriver

Artnr: FPHF201
Du måste vara inloggad för att köpa produkten. Registrera dig här.
Artnr: FPHF201-16
Du måste vara inloggad för att köpa produkten. Registrera dig här.

Beskrivning



FaitalPro HF201 - 2" kompressionsdriver



Technical Parameters
Nominal Impedance 8 Ohm
Minimum Impedance 7.2 Ohm
AES Power above 0.9 kHz (1) 100 W
AES Power above 0.65 kHz 50 W
Maximum Power above 0.9 kHz (2) 200 W
Maximum Power above 0.65 kHz 100 W
Minimum Crossover Frequency (3) 0.9 kHz
Sensitivity (1W/1m) (4) 108 dB
Frequency Range 0.5÷18 kHz
Voice Coil Diameter 74 mm (2.91 in)
Winding Material Al
Former Material Kapton
Diaphragm Material Titanium
Diaphragm Shape Dome
Winding Depth 2.35 mm (0.09 in)
Magnetic Gap Depth 3.2 mm (0.13 in)
Flux Density 1.7 T
Magnet Ferrite Ring
Re 5.6 Ohm
Phase Plug Design Annular
NET Air Volume filled by HF Driver 1.05 dm^3 (0.037 ft^3)
Nominal Specifications
Throat Diameter 50.8 mm (2 in)
Overall Diameter 170 mm (6.69 in)
90° Mounting Holes Diameter (4xM6) 102 mm (4.02 in)
Depth 66 mm (2.60 in)
Net Weight 4.6 Kg (10.2 lb)
Shipping Box 195 x 195 x 141 mm
(7.7 x 7.7 x 5.6 in)
Shipping Weight 4.8 Kg (10.6 lb)
