FaitalPro 18HP1042 - 18" högtalarelement



Nominal Specifications
Nominal Diameter 460 mm (18 in)
Overall Diameter 460 mm (18.11 in)
Bolt Circle Diameter 440 mm (17.32 in)
Baffle Cutout Diameter 422 mm (16.61 in)
Depth 202 mm (7.95 in)
Flange and Gasket Thickness 14 mm (0.55 in)
Net Weight 6.7 Kg (14.8 lb)
Shipping Box
(Single Carton Box)		 503 x 500 x 258 mm
(19.8 x 19.7 x 10.2 in)
Shipping Weight 7.8 Kg (17.2 lb)


Technical Parameters
Nominal Impedance 8 Ohm
Minimum Impedance 6.6 Ohm
AES Power Handling (1) 1000 W
Maximum Power Handling (2) 2000 W
Sensitivity (1W/1m) 98 dB
Frequency Range 38÷2500 Hz
Voice Coil Diameter 100 mm (4 in)
Winding Material Al
Former Material Glass Fiber
Winding Depth 22 mm (0.87 in)
Magnetic Gap Depth 12 mm (0.47 in)
Flux Density 1.3 T
Magnet Neodymium Slug
Basket Material Aluminum
Demodulation No
Cone Surround (3) Triple Roll
NET Air Volume filled by Loudspeaker 5.8 dm^3 (0.205 ft^3)
Spider Profile 2x non-adjacent symmetrical constant height waves
Thiele and small parameters
Fs 38 Hz
Re 5.5 Ohm
Qes 0.43
Qms 10.3
Qts 0.42
Vas 151 dm^3 (5.33 ft^3)
Sd 1124 cm^2 (174.22 in^2)
Xmax (4) 9.00 mm
Xdamage (5) 17.5 mm
Mms 187.5 g
Bl 24.5 N/A
Le 1.26 mH
Mmd 166.2 g
Cms 0.08 mm/N
Rms 4.58 Kg/s
Eta Zero 2.1 %
EBP 88 Hz
